Our Steel Bracing not only focuses on load-bearing capacity and stability, but also promotes green and efficient construction. Utilizing high-strength Q235/Q345 steel and featuring a hot-dip galvanizing process for corrosion protection, the product can be used continuously for over 300 cycles, significantly reducing the consumption of disposable materials such as wood planks and bamboo plywood, reducing construction waste and helping projects achieve environmental goals.
The threaded adjustment design makes installation and disassembly faster, allowing ordinary workers to perform the operation independently. This reduces labor input by an average of 20–30% and shortens the overall construction period by 10–15%. Whether it's floor slab pouring, beam and column support, or foundation pit reinforcement, our Steel Bracing helps contractors achieve higher efficiency and a lower carbon footprint.
Reduces wood use by 30–40%, lowering waste disposal costs.
Smooth thread adjustment, single-person operation possible, shortens construction time by 10–15%.
Hot-dip galvanized surface for corrosion resistance, offering an 8–10-year service life.
300+ turnovers, lowering total costs and improving capital utilization.
One system can be used for different types of projects, reducing inventory requirements.
| Italian Steel Support Specifications | ||||
|---|---|---|---|---|
| Wall Thickness | Min Height | Max Height | Outer Pipe Diameter | Inner Pipe Diameter |
| 1.5 - 3.5mm | 1.7m | 3.0m | 56mm | 48mm |
| 1.8m | 3.2m | 56mm | 48mm | |
| 2.0m | 3.5m | 56mm | 48mm | |
| 2.0m | 3.6m | 56mm | 48mm | |
| 2.2m | 4.0m | 56mm | 48mm | |
| 2.5m | 4.5m | 56mm | 48mm | |
| 2.8m | 5.0m | 56mm | 48mm | |
| 3.0m | 5.0m | 56mm | 48mm | |
| 3.5m | 6.0m | 56mm | 48mm | |
| Surface Treatment | Spraying, powder spraying, electro-galvanizing, hot-dip galvanizing | |||
| Other specifications can be customized as per your requirements. | ||||
| Middle Eastern and German-Style Steel Support Specifications | ||||
|---|---|---|---|---|
| Wall Thickness | Min Height | Max Height | Outer Pipe Diameter | Inner Pipe Diameter |
| 1.5 - 3.5mm | 1.7m | 3.0m | 60mm | 48mm |
| 1.8m | 3.2m | 60mm | 48mm | |
| 2.0m | 3.5m | 60mm | 48mm | |
| 2.0m | 3.6m | 60mm | 48mm | |
| 2.2m | 4.0m | 60mm | 48mm | |
| 2.5m | 4.5m | 60mm | 48mm | |
| 2.8m | 5.0m | 60mm | 48mm | |
| 3.0m | 5.0m | 60mm | 48mm | |
| 3.5m | 6.0m | 60mm | 48mm | |
| Surface Treatment | Spraying, powder spraying, electro-galvanizing, hot-dip galvanizing | |||
| Other specifications can be customized as per your requirements. | ||||
In 2024, a new office and R&D complex was constructed in a modern Smart Park, with a total construction area of approximately 25,000 square meters and floor heights ranging from one basement floor to eight above-ground floors. The project placed extremely high demands on construction efficiency, cost control, and environmental friendliness.
The project fully utilized 4,500 sets of adjustable steel supports, replacing traditional timber and disposable support systems. Support heights can be flexibly adjusted from 1.5 to 6 meters, adapting to different floor and beam and slab heights. Hot-dip galvanized surface treatment provides corrosion and wear resistance, suitable for multi-layer pouring and use in humid environments.
Each steel support can be reused over 300 times, significantly reducing material procurement and long-term project costs.
Quick thread adjustment allows single-person installation, saving 20-30% in labor costs and shortening project schedules by 10-15%.
Made of high-strength Q235/Q345 steel, with a hot-dip galvanized or painted finish, it ensures long-term durability even in humid or concrete-intensive environments.
Suitable for floor slabs, beams, foundations, bridges, and tunnel projects, one system can meet a variety of construction needs.
Reduces the use of disposable wood and materials by up to 40%, reducing construction waste and supporting environmentally friendly building practices.
Widely used in domestic and international projects, including residential communities, infrastructure, and subway construction, it has received high praise from customers.
Our steel shoring can be reused over 300 times, reducing the use of disposable timber and other consumables, lowering construction waste, and complying with green building and sustainable construction standards.
In actual projects, using our steel shoring can reduce timber consumption by 30–40% and reduce construction waste by approximately 30 tons per project, significantly improving the environmental performance of construction.
Using hot-dip galvanizing or environmentally friendly spray painting for surface treatment not only improves corrosion resistance and service life, but also reduces repeated replacement and waste generation, achieving long-term environmental benefits.
Yes, our steel shoring is designed for multi-project turnover, reducing the frequency of new material procurement, and lowering carbon emissions and resource waste.
High turnover and quick adjustment design improve construction efficiency, save labor and material costs, while reducing additional consumption on the environment and achieving green and economical construction.
